TW1 - Mineral Insulated w/ Coil Cord Thermocouple Configurator
Data Sheet
Calibration
Type J
Type K
Type T
Type E
Type J (Special Limits)
Type K (Special Limits)
Type T (Special Limits)
Type E (Special Limits)
Sheath Diameter
0.062" (1.6mm)(1/16")
0.079" (2mm)
0.092" (2.3mm)
0.118" (3mm)
0.125" (3.2mm) (1/8")
0.156" (4mm)
0.177" (4.5mm)
0.188" (4.8mm) (3/16")
0.236" (6mm)
0.250" (6.4mm) (1/4")
Sheath Material
304SS
316SS
NCONEL (600)
446SS
310SS
Hastelloy
Pyrosil D
Sheath Length (0.25-600 inches)
Junction
Grounded (Single)
Ungrounded (Single)
Exposed (Single)
Exposed & recessed (Single)
Transition Fitting
3/8"OD X 1.25" w/ strain relief spring
1/4"OD X 1.25" w/ strain relief spring
3/8"OD X 1.25" (no spring)
1/4"OD X 1.25" (no spring)
Coil Cord Style
10" coil cord (extends to approx. 6ft) (220°F)
24" coil cord (extends to approx. 14ft) (220°F)
Termination Style
2" stripped leads (bare ends)
2" stripped leads w/ spade lugs
Standard male plug (400°F)
Solid pin plug
Standard female jack (400°F)
Miniature plug (400°F)
Miniature jack (400°F)
2" stripped leads w/ #6 Ring terminals
2" stripped leads w/ pin terminals
2" stripped leads w/ wire ferrules
Extra long lead wire length (beyond 2" stripped leads)
Special Features (Optional)
Drill point tip
Cable Clamp
Bx Connector
Mating connector
Moisture protection boot on connector
Fluoropolymer covered probe
